SS tank 1000l with insulating layer

SS TANK 1000L WITH INSULATING LAYER DESCRIPTION

The cover plate of this stainless steel tank is made of 304 stainless steel plate by a one-time stamping mold, Eight Vertex Angles without splicing welds, the cover plate has a reinforcement design, and the side plate is welded with the cover plate after bending. The welding process is TIG welding. With a capacity of 1000 litres, it is designed for the safe storage and transport of liquid or granular materials.

The outer frame is made of galvanized round pipe by automatic welding, and SS304 stainless steel outer frame can also be customized. The outer frame can be stacked, and reused.

This SS tank is equipped with atmospheric manhole and vent valve at the top, and standard discharge valve at the bottom to support fast emptying.

Manhole and valve size can be customized,The SS tank combines durability, safety and economy with a service life of more than 10 years, making it an ideal alternative to traditional plastic tank.

The inner layer of this double-layer thermal insulation tank is made of 316L stainless steel and the outer layer is made of 304 stainless steel. The thickness of the insulation layer is 30mm. The six sides of the container are filled with polyurethane insulation materials, and can also be filled with materials with better thermal insulation properties as required. This designed tank is suitable for use in cold areas in winter, as well as some liquid materials that need to be insulated.
